Traction mainly with plastic extrusion line, cutting machine for plastic pipe material, molding and extrusion production line of products. The cutting machine for Siemens PLC control, manual and automatic cutting in two ways. Manual cutting can use either when cutting, automatic cutting is according to user's choice of fixed length, or encoder feedback signal by travel switch cutting, wide application, use and reliable.
|
model |
DY-600D |
DY-1 |
DY-2 |
DY-3 |
DY-3A |
|
Traction speed (m/min) |
0.3-10 |
0.4-5 |
0.3-5 |
||
|
Traction maximum size (mm) |
80*80 |
120*120 |
150*150 |
210*160 |
210*160 |
|
Traction center height (mm) |
800-1000 |
800-1000 |
1000-1100 |
950-1050 |
800-4000 |
|
Traction power (kw) |
0.75 |
1.5 |
3 |
4 |
5.5 |
|
Overall dimensions |
1000*550*1500 |
1250*650*1600 |
1550*800*1750 |
2740*1200*1800 |
2200*1000*1750 |
|
Weight (kg) |
400 |
500 |
700 |
1200 |
300 |
Multiple crawler tractor technical parameters:
|
Model |
SZ3 |
SZ4 |
SZ6 |
SZ8 |
|
Traction speed m/min |
0.5-5 |
0.34-3 |
0.2-2 |
0.1-0.8 |
|
maximum traction N |
20000 |
30000 |
48000 |
50000 |
|
main motor kW power |
2.2 |
4 |
7.5 |
15 |
|
total power |
4 |
5.5 |
7.5 |
15 |
|
center height mm |
1000-1100 |
1000-1100 |
1000-1200 |
1150-1300 |
|
effective length of traction :mm |
1200 |
1300 |
1800 |
1800 |
|
Traction mm pipe specifications mm |
Ф50-Ф250 |
Ф110-Ф315 |
Ф200-Ф500 |
Ф315Ф-Ф63050 |
|
weight kg |
2500 |
3000 |
4000 |
5000 |
|
dimensions mm |
2500*1300*2000 |
2870*1585*2250 |
3440*2000*2500 |
2940*2560*2900 |
Tractor technical parameters:
|
Main Technical Standards Model |
DYC1-800 |
DYC1-1500 |
DYC2-2000 |
|
Drawing speed: m/min |
1-10 |
0.5-8 |
0.5-8 |
|
Max.drawing height:mm |
950-1100 |
950-1100 |
950-1100 |
|
Drawing power:kw |
2.2 |
4 |
5.5 |
|
Appearance size:mm |
1800*885*1720 |
2200*900*1720 |
2800*1015*1720 |
